DeTong KF-9GW 9,000 BTU Mini Split AC | Heating & Cooling

DeTong KF-9GW 9,000 BTU Mini Split AC | Heating & Cooling

  • Cooling Capacity 9,000 BTU
  • Climate Type T1 (Tropical)
  • Compressor Brand LG Rotary
  • Refrigerant R410A / R32
  • 40HQ Load 370 PCS
All Products

Technical Specifications

Product Name Wall Split Air Conditioner
Model KF-9GW
Cooling Capacity 9,000 BTU
Power 3,500W
Power Supply 220V-240V / 50Hz / 1P
Climate Type T1
Compressor Brand LG Rotary Compressor
Refrigerant R410A / R32
Cool/Heat Type Cooling Only / Cooling & Heating
Type On-Off / Inverter
Indoor Unit Size 703 × 255 × 193 mm
Indoor Package Size 765 × 325 × 270 mm
Indoor Net/Gross Weight 6.5 / 7.0 KG
Outdoor Unit Size 639 × 270 × 500 mm
Outdoor Package Size 695 × 295 × 560 mm
Outdoor Net/Gross Weight 22.5 / 24.0 KG
Connecting Pipe 2.6M AL + Copper Pipe
Application Hotel, Commercial, Household
Control Method Remote Control
Place of Origin Zhejiang, China
Brand DeTong
After-Sales Service Free Spare Parts
Warranty 2 Years
40HQ Container Load 370 PCS

Product Description

Why the KF-9GW Belongs in Your Bedroom

A good night's sleep shouldn't come with compressor hum. The DeTong KF-9GW 9,000 BTU mini split AC was engineered from the ground up for noise-sensitive spaces — bedrooms, hotel guest rooms, and home offices where concentration and rest matter. Operating at just 40 dB(A), it's quieter than a library whisper, yet delivers 9,000 BTU of cooling power to rooms up to 25㎡. With an LG rotary compressor at its core and gold-plated FIN anti-corrosion technology protecting the heat exchanger, this unit is built to perform reliably season after season, even in humid coastal environments.

Quiet by Design — Features for Restful Spaces

◆ Sleep Mode: Gradually adjusts the set temperature throughout the night — cooler for deep sleep, slightly warmer toward morning — mimicking the body's natural thermal rhythm. No more waking up freezing at 3 AM.

◆ 40 dB(A) Noise Floor: Achieved through an acoustically optimized fan blade design and vibration-dampened compressor mounting. At this level, typical background noise in a quiet room masks the AC entirely.

◆ ECO Energy Saver: When the room reaches your set temperature, the compressor intelligently cycles off while the fan continues circulating cool air. This cuts power draw by up to 30% during steady-state operation — noticeable on your monthly bill.

◆ 3-Speed Fan + 4D Airflow: Direct cool air where you need it. The 4D deflection system prevents cold spots and drafts, maintaining ±1°C temperature consistency across the room.

◆ 6-in-1 Modes: Cooling, Heating, Dry, Dehumidifying, Auto, and Fan — one unit handles every season. The Dry mode alone can remove up to 3.9 pints of moisture per hour, making humid summer nights feel crisp.

◆ 3-Second Fast Heat: On chilly mornings, warm air flows within 3 seconds of activation — no long wait for the compressor to ramp up.

What's Inside — Technology That Lasts

◆ LG Rotary Compressor (T1 Rated): We chose LG compressors because they withstand sustained tropical operation — the kind of continuous duty that burns out generic units within two seasons. T1 classification means it's certified for ambient temperatures up to 52°C.

◆ Gold-Plated FIN Heat Exchanger: A proprietary anti-corrosion coating protects the aluminum fins from salt spray, humidity, and acidic rain. This is the same technology used in coastal resort installations where standard AC coils fail within 18 months. Effective heating maintained down to -25°C ambient.

◆ R410A / R32 Refrigerant Options: Standard R410A for markets with established supply chains; lower-GWP R32 for regions transitioning to environmentally preferred refrigerants under Kigali Amendment timelines.

◆ Quality & Compliance: Manufactured under ISO 9001 quality management. All materials are CE and RoHS compliant. Each unit undergoes a 45-minute factory run-test before packaging — not a statistical sample, every single unit.

Where It Fits

◆ Master Bedrooms & Guest Rooms: The primary use case. At 40dB and with Sleep Mode, it's purpose-built for this. Indoor unit (703×255×193mm) mounts above head height with minimal visual intrusion.

◆ Hotel & Boutique Accommodations: Installers value the 2.6M pre-flared copper-aluminum connection pipe included in the kit. Maintenance teams appreciate tool-free filter access for quick turnaround cleaning.

◆ Home Offices & Studies: The white textured panel with silk-screen printed DeTong branding looks professional on video calls. ECO mode keeps running costs low during 8-hour workdays.

◆ Clinics & Consulting Rooms: Quiet operation maintains a professional, calming environment for patients and clients.

Specifications at a Glance

Cooling: 9,000 BTU | Power: 220-240V/50Hz/1P | Indoor: 703×255×193mm, 6.5KG | Outdoor: 639×270×500mm, 22.5KG | Refrigerant: R410A or R32 | Compressor: LG Rotary (T1) | Noise: 40 dB(A) | Coverage: up to 25㎡ | Warranty: 2 years with free spare parts | Container: 370 units/40HQ | Origin: Zhejiang, China.
